Marine Deck 3T Fixed Boom 9m CCS Hydraulic Jib Crane

Contact Now
WUXI OUCO INTERNATIONAL GROUP CO., LTD
Visit Website
City:wuxi
Province/State:jiangsu
Country/Region:china
Contact Person:MsNatalie Liu
Contact Now

Marine Deck 3T Fixed Boom 9m CCS Hydraulic Jib Crane

Ask Latest Price
Video Channel
Brand Name :OUCO
Model Number :OUCO-TB-5T13.5M
Certification :ISO9001/CE/ABS/CCS/BV
Place of Origin :Jiangsu, China
MOQ :1 set
Supply Ability :100 sets per year
Delivery Time :60 days
Packaging Details :Shipping Container/Wood Crate/nude
warranty :1 year
Slewing angle :360 degree free
Boom type :fixed
Material :Steel Structure
Usage :marine deck
Luffing :75 degree
Max. working radius :9m
Min. working radius :3m
Price :Negotiation
more
Contact Now

Add to Cart

Find Similar Videos
Soft Start Marine Ship Deck Crane Folding Telescopic Boom 1.5T7.8M 00:33
Soft Start Marine Ship Deck Crane Folding Telescopic Boom 1.5T7.8M
5M Stiff Boom 360 Degree Marine 4t Pedestal Jib Crane 00:31
5M Stiff Boom 360 Degree Marine 4t Pedestal Jib Crane
2.5t 22m Folding Boom Ship Deck Cranes Hydraulic With Telescopic 00:30
2.5t 22m Folding Boom Ship Deck Cranes Hydraulic With Telescopic
1.5T4M Small Ship Deck Cranes Lifting Hydraulic Boom Yacht 00:30
1.5T4M Small Ship Deck Cranes Lifting Hydraulic Boom Yacht
ABS Certification Passed Knuckle Marine Deck/Shipboard Boom Crane 01:49
ABS Certification Passed Knuckle Marine Deck/Shipboard Boom Crane
Innovative 0.5 Ton Provision Crane Knuckle And Telescopic Boom On Ship 00:33
Innovative 0.5 Ton Provision Crane Knuckle And Telescopic Boom On Ship
8T Active Heave-compensated Subsea Crane With Knuckle Boom 00:49
8T Active Heave-compensated Subsea Crane With Knuckle Boom
30t Container Lifting Spreader 00:41
30t Container Lifting Spreader
10t Standard Tonnage Straight Arm Small Lorry Mounted Crane 00:27
10t Standard Tonnage Straight Arm Small Lorry Mounted Crane
View Product Description

Marine Deck 3T Fixed Boom 9m CCS Hydraulic Jib Crane

Product Description

Our Fixed Boom Cranes utilize a more compact design to offer more portability and easier maintenance. Fixed Boom Cranes are available in 3 - 100 ton capacity. We can design and build to your specifications. These cranes are typically utilized for offshore and/or fixed platform work. This crane is used especially on barges and lift boats. Each of our Cranes is meticulously manufactured for efficiency, maintenance, and affordability.

Specification

1 SWL 3T@9M
2 MAX WORKING RADIUS 9m
3 MIN WORKING RADIUS 3m
4 HOISTING SPEED 0~10m/min
5 HOISTING HEIGHT 20m
6 SLEWING SPEED ~0.8r/min
7 SLEWING ANGLE 360°
8 LUFFING TIME ~ 45s
9

EXTENSION TIME

~0s
10

WORKING CONDITION

TRIM ≤2°

HEEL ≤5°

11 MOTOR

ELEC-MOTOR POWER Y160K-4-H

POWER 15kw

Speed 1460r/min

POWER RESOURCE AC415V/50HZ

12 PROTECT CLASS IP56
13 INSULATE CLASS F
14 WORKING TYPE S1

SB series crane: End User Advantages:

1. Compact design

2. Small footprint

3. Delivered as one complete unit ready for installation to vessels

4. Easy access for periodic maintenance, service and repair

5.24 hours after sales searvices support.

Marine Deck 3T Fixed Boom 9m CCS Hydraulic Jib Crane


GA drawing

Marine Deck 3T Fixed Boom 9m CCS Hydraulic Jib Crane

Our Company

Marine Deck 3T Fixed Boom 9m CCS Hydraulic Jib Crane

OUCO Industry, was established in February 1984, covers an area of 48,000 square meters, construction area is 35,000 square meters.

OUCO headquartered in crane hometown of Jiangsu Province where representing most advanced machinery manufacturing level in China.

OUCO has more than 150 employees, 20 are technical staff. Among that has five senior titles, 10 mid-level titles, and a total of 50 welder (who has got CCS, ABS and other main institutions’ certification). It also has professional organization certificated flaw detection staff, the quality system audit staff, and inspection personnel, etc.

OUCO provides high quality handling solutions and access systems for the Crane, port industries and various non-standard structural parts. The company has its own developing, designing, and manufacturing capacity for products of metallurgical complete sets of equipment, marine cranes, truck cranes, boiler desulfurization and denitrification environmental protection products in air pollution control field. Company products are widely used in the metallurgical, ship, port, electricity, petroleum, building materials and chemical industries.

OUCO has subsidiaries in several countries and serves a global client base from strategic points in Europe, Asia, Africa, Australia and Middle East. It has an annual output of 11,000 tons of steel structure production capacity.
